Αρχική Σελίδα ΠροϊόνταΣύστημα διαχωριστικών τειχών από γυαλίPanoramic Double-Glass Partition System single glass partition wall with middle frosted
Panoramic Double-Glass Partition System single glass partition wall with middle frosted
Panoramic Double-Glass Partition System single glass partition wall with middle frosted
Panoramic Double-Glass Partition System single glass partition wall with middle frosted Panoramic Double-Glass Partition System single glass partition wall with middle frosted

Panoramic Double-Glass Partition System single glass partition wall with middle frosted

Λεπτομέρειες:
Place of Origin: China
Μάρκα: Glawall
Πιστοποίηση: SGS, ISO 9001,UL, CE
Model Number: Panoramic Double-Glass
Πληρωμής & Αποστολής Όροι:
Minimum Order Quantity: 10 square meters
Τιμή: US$80.00 10 - 99 square meters
Packaging Details: wooden package
Delivery Time: 2-3 weeks
Payment Terms: L/C,D/A,D/P,T/T,Western Union
Supply Ability: 3000 square maters per month
Επικοινωνήστε

Λεπτομερής ενημέρωση
Material: Aluminum frame+glass panel Transparency: Clear
Customizable: size, accessories Competitive price: yes
Glass Thickness: 12mm glass type: strong tempered glass
Frame Material: Aluminum Advantage: Competitive price, good service, high professional, quality guarantee

Περιγραφή προϊόντων

Panoramic Double-Glass Partition System single glass partition wall with middle frosted 0


Panoramic Double-Glass Partition System – Technical Specifications


1. System Overview
A sleek, high-performance glass partition system designed for offices, exhibition halls, and premium spaces, combining maximum transparency with superior acoustics.


2. Core Specifications

Parameter Specification
Glass Type     Double-layer tempered safety glass (10mm+10mm, 10mm+12mm, or 12mm+12mm)
Wall Thickness 83mm / 100mm
Max Height <3200mm (custom heights available with reinforcement)
Frame Profile 35mm ultra-slim aluminum
Glass Connection Transparent acrylic tape / metal ultra-narrow strips / crystal beading
Sound Insulation (Rw) 42-48dB (upgradable to 50dB with laminated glass)
Sound Absorption >0.9 (with optional perforated metal or 3D polyester fiber panels)


Panoramic Double-Glass Partition System single glass partition wall with middle frosted 1


3. Key Features


✔ Seamless, Frameless Aesthetic Panoramic glass-to-glass joints (near-invisible connections)
35mm slim frame for a minimalist, high-end look
✔ Superior Acoustic Performance Double-glazed construction with 6-16mm air gap
Optional sound-absorbing panels (perforated metal or 3D fiber)
✔ Premium Door Options Door Type Best For
Single Glass Door Minimalist entryways
Framed Double-Glass Door Enhanced soundproofing
Wood Grain / Steel Door High-security areas
Sliding Glass Door Space-saving solutions
✔ Smart Office Integration Pre-wired for power/AV (hidden in frames)
Compatible with smart glass (PDLC) for instant privacy


Panoramic Double-Glass Partition System single glass partition wall with middle frosted 2


4. Applications
✔ Corporate offices (executive suites, meeting rooms)
✔ Luxury retail (showroom dividers)
✔ Exhibition halls (seamless displays)
✔ Hospitality (hotel lobbies, VIP areas)


5. Why Choose This System?
✅ Uninterrupted views – Maximizes natural light
✅ High soundproofing – Ideal for confidential discussions
✅ Easy installation – Modular, pre-assembled components
✅ Customizable – Frosted, tinted, or switchable glass


"Where elegance meets engineering—creating boundaries that inspire."
